2 In 1 Combine M.2 NGFF Key B & MSATA SSD To SATA3 Adapter Seamless Integration
تفاصيل المنتج:
| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | BQZYX |
| رقم الموديل: | زي اكس 147 |
شروط الدفع والشحن:
| الحد الأدنى لكمية: | 50-100 قطعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | حقيبة كهرباء |
| وقت التسليم: | 10-15 أيام العمل |
| شروط الدفع: | T/T ، Western Union |
| القدرة على العرض: | 190000 قطعة شهريا |
|
معلومات تفصيلية |
|||
| اسم المنتج: | محول بطاقة محول SSD لبروتوكول SATA | ترتيب الفتحة: | موازي |
|---|---|---|---|
| فتحة SSD 1: | NGFF (M.2) المفتاح-B | حجم الدعم1: | 22*30 مللي متر (اتفاقية ساتا) |
| حجم الدعم2: | 22*42 مللي متر (اتفاقية ساتا) | حجم الدعم3: | 22*60 مللي متر (اتفاقية ساتا) |
| حجم الدعم4: | 22*80 مللي متر (اتفاقية ساتا) | فتحة SSD 2: | فتحة mSATA |
| حجم الدعم 5: | الارتفاع الكامل/نصف الارتفاع | واجهة الإخراج: | سات 3.0 |
| مميزات المنتج 1: | تبديل تقلب اختيار SSD | مميزات المنتج 2: | ضوء مؤشر LED |
| إبراز: | Combine M.2 NGFF To SATA3 Adapter,mSATA SSD To SATA3 Adapter,M.2 NGFF To SATA3 Adapter,mSATA SSD To SATA3 Adapter,M.2 NGFF To SATA3 Adapter |
||
منتوج وصف
2 In 1 Combine M.2 NGFF Key B & MSATA SSD To SATA3 Adapter
This dual SATA protocol SSD to SATA3.0 adapter provides seamless integration for both M.2 NGFF Key B and mSATA SSDs, offering flexible storage expansion with high-speed data transfer capabilities.
Key Specifications
- Supports full size mSATA SSD
- Compatible with NGFF M.2 Key B SATA-bus SSD
- Accommodates 4 sizes of NGFF M.2 Socket SSD: 2230/2242/2260/2280
- Transparent to operating system - no drivers required
- LED power status indicator
- Hi-Speed SATA3/6Gbps mass storage interface
Product Overview
This innovative adapter serves as a flexible storage bridge with parallel M.2 KEY-B and mSATA slots, enabling simultaneous installation of two different SSDs. The integrated toggle switch allows easy selection between installed drives, while the LED indicator provides clear operational status.
Core Features
Dual Slot Compatibility
The M.2 KEY-B slot precisely accommodates SATA protocol SSDs in four standard sizes (2230/2242/2260/2280), while the mSATA slot supports both full and half height SSDs. Gold-plated contacts ensure optimal conductivity and connection stability.
High Performance Interface
The SATA3.0 output interface delivers 6Gbps transfer speeds, maintaining near-theoretical performance for fast system boot, application loading, and file transfers.
Intelligent Control
The physical toggle switch enables instant selection between installed SSDs, while the LED indicator provides visual confirmation of active drive and power status.
Technical Specifications
Data Interface (7-pin)
| Pin | Definition | Function |
|---|---|---|
| 1 | GND Ground | Grounding, usually connected to the negative pole |
| 2 | A Transmit | Positive signal interface for data transmission |
| 3 | A Transmit | Data transmission negative signal interface |
| 4 | GND Ground | Grounding, usually connected to the negative pole |
| 5 | B-Receive | Data receiving negative signal interface |
| 6 | B-Receive | Data receiving positive signal interface |
| 7 | GND Ground | Grounding, usually connected to the negative pole |
Power Interface (15 Pin)
| Pin | Signal | Wire Color | Definition |
|---|---|---|---|
| 1 | +3.3VDC | Orange | DC 3.3V positive power supply pin |
| 2 | +3.3VDC | Orange | DC 3.3V positive power supply pin |
| 3 | +3.3VDC | Orange | DC 3.3V positive power pin, pre charged |
| 4 | GND | Black | Grounding, usually connected to the negative pole |
| 5 | GND | Black | Grounding, usually connected to the negative pole |
| 6 | GND | Black | Grounding, usually connected to the negative pole |
| 7 | +5VDC | Red | DC 5V positive power pin, pre charged |
| 8 | +5VDC | Red | DC 5V positive power supply pin |
| 9 | +5VDC | Red | DC 5V positive power supply pin |
| 10 | GND | Black | Grounding, usually connected to the negative pole |
| 11 | Optional | Black | Reserved pins |
| 12 | GND | Black | Grounding, usually connected to the negative pole |
| 13 | +12VDC | Yellow | DC 12V positive power pin, pre charged |
| 14 | +12VDC | Yellow | DC 12V positive power supply pin |
| 15 | +12VDC | Yellow | DC 12V positive power supply pin |
Package Contents
- 1 x PCBA Adapter
- 1 x Screw Driver
- 4 x M2 Screw
- 6 x M3 Screw
- 2 x Standoff
Product Images
