RAM DDR4 260Pin Slot To Desktop DDR4 DIMM Adapter Test Protection Card
تفاصيل المنتج:
| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | BQZYX |
| رقم الموديل: | ZYX258 |
شروط الدفع والشحن:
| الحد الأدنى لكمية: | 50-100 قطعة |
|---|---|
| الأسعار: | قابل للتفاوض |
| وقت التسليم: | 10-15 أيام العمل |
| شروط الدفع: | T/T ، Western Union |
| القدرة على العرض: | 190000 قطعة شهريا |
|
معلومات تفصيلية |
|||
| اسم العلامة التجارية: | BQZYX | اسم المنتج: | بطاقة حماية اختبار الذاكرة SO-DIMM DDR4 260pin |
|---|---|---|---|
| يكتب: | بطاقة اختبار | مادة: | PCBA |
| الاتجاه 1: | إلى الأمام DDR4 | الاتجاه 2: | عكس DDR4 |
| بُعد المنتج: | 68*20 مللي متر | ميزة: | تصميم تصميم ثنائي الفينيل متعدد الكلور ذو 4 طبقات |
| واجهة: | SO-DIMM DDR4 260pin | لون المنتج: | أخضر |
| إبراز: | Desktop DDR4 DIMM Adapter,Laptop DDR4 260Pin Slot,260Pin Slot DDR4 DIMM Adapter,Laptop DDR4 260Pin Slot,260Pin Slot DDR4 DIMM Adapter |
||
منتوج وصف
RAM DDR4 260Pin Slot To Desktop DDR4 DIMM Adapter Test Protection Card
Laptop SO-DIMM Memory RAM DDR4 260Pin Slot To Desktop DDR4 DIMM Adapter Test Protection Card.
Product Specifications
- Widely used as a powerful test tool and fixture for engineers and factories
- Reduces golden finger abrasion of SO DDR4 Memory cards during testing
- Lowers factory manufacturing costs
- SO-DIMM DDR4 260pin memory test protection card
- Compatible with SO DDR4 memory cards for notebook PCs
- Working voltage: 1.2V DC
- No additional drivers required
- 4-Layer PCB design reduces signal loss and EMI
- Dimensions: 70x20mm
Product Overview
This SO-DDR4 memory module testing protection card serves as an essential tool for engineers and factories in laptop memory module testing and adaptation. Its professional design with a four-layer PCB creates a high-speed pathway for signal transmission while minimizing signal loss and EMI. The adapter significantly reduces wear on DDR4 memory modules during frequent testing operations, lowering manufacturing costs and improving production efficiency.
Product Features
Excellent Gold Finger Protection Performance
Features a special soft material contact structure and fine elastic design that gently fits with gold fingers, preventing scratches and wear during testing. This extends memory module lifespan and reduces scrap rates.
Efficient Four Layer PCB Architecture
The four-layer design includes a low-loss signal layer, stable power layer, and effective shielding layer that work together to ensure high-speed signal transmission while minimizing EMI interference for accurate test results.
Precise 260Pin Adaptation Features
Each pin is manufactured to strict DDR4 standards with dimensional accuracy for perfect fit with memory module gold fingers. Provides smooth insertion and secure connection without looseness or poor contact.
Wide Range of Application Adaptability
Compatible with various notebook DDR4 memory module models across different brands, capacities, and frequencies that meet DDR4 standards, providing a universal testing solution.
Product Structure and Interface
SO-DDR4 Memory Module Slot
High-precision 260Pin slot with gold-plated contacts ensures perfect fit and conductivity. Features soft guiding angles and automatic locking mechanism for secure memory module installation.
Four Layer PCB Board
Precision-designed layers include signal transmission, power regulation, EMI shielding, and structural support connected through precise vias for optimal performance.
External Interface
Standard interface with high-strength engineering plastic housing provides secure connection to testing equipment with automatic locking mechanism.
Performance Advantages
- Cost Reduction: Minimizes memory module wear during testing, reducing scrap rates and lowering production costs
- Signal Quality Assurance: Maintains pure and stable DDR4 signals in testing environments for accurate results
- Testing Efficiency: Quick installation and wide compatibility streamline testing processes
Usage Method
- Align and insert adapter card into testing device until securely connected
- Insert DDR4 memory module into 260Pin slot with correct orientation
- Verify secure connections before starting tests
- Monitor memory module performance during testing
Applicable Scenarios
- Electronic Engineering Laboratories: For DDR4 memory module performance testing and development
- Computer Hardware Manufacturing: Essential tool for memory module production line testing
260 Pin SO-DIMM DDR4 Memory Module Pin Configuration
| Function | Pins |
|---|---|
| Power supply and grounding | VDD, VSS, VDDQ |
| Address and control signals | A0-A15, BA0-BA2, CS#, RAS#, CAS#, WE# |
| Data bus | DQ0-DQ7, DM |
| Clock signal | CK_t/CK_c, CKE |
| Reference voltage | VREF_CA, VREF_DQ |
| Other control signals | ZQ, ODT |
